Feature
Applicable to tugboats and push boats
|
Specification：
|
Type
|
Inner Dia
(d)
|
Outer Dia
(D)
|
Length of product
(L)
|
Note
|
D |
D' |
Φ200×Φ100×L |
100 |
200 |
|
500-20000 |
Straight
Type
|
Φ300×Φ150×L |
150 |
300 |
|
Φ400×Φ200×L |
200 |
400 |
|
Φ500×Φ220×L |
220 |
500 |
|
Φ500×Φ250×L |
250 |
500 |
|
Φ600×Φ300×L |
300 |
600 |
|
Φ700×Φ350×L |
350 |
700 |
|
Φ750×Φ350×L |
350 |
750 |
|
Φ800×Φ400×L |
400 |
800 |
|
Φ400×Φ300×Φ200×L |
200 |
400 |
300 |
Cone
Type
|
Φ500×Φ400×Φ250×L |
250 |
500 |
400 |
Φ600×Φ450×Φ250×L |
250 |
600 |
450 |
Φ700×Φ500×Φ300×L |
300 |
700 |
500 |
Φ750×Φ450×Φ250×L |
250 |
750 |
450 |
Φ760×Φ500×Φ300×L |
300 |
760 |
500 |
Φ800×Φ600×Φ400×L |
400 |
800 |
600 |
Note:
1.The Specification of the aboveA、B can be determined by the user. It has two kinds of R、H i.e. R15、H30 and R25、H50.
2.Products of other sizes can be manufactured at users' request.
3.Rubber stopper is avaiable for easy-installation.
|
|
| |
 |
