Molded gratings

☉Characteristics:

Chemical Factory	High Strength & Light Weight
Impact Resistance	Fire Retardant
Non-Conductive	Slip Resistance
Non-Magnetic	Non-Sparking
Attractive and Maintenance Freedom	Installation Easy
Anti-Fatigue	Long Service Life

☉Used Fields:

Chemical Factory	Smeltery
Sewage Treatment	Electronics Industry
Oil Chemical Industry	Marine Exploration
Pharmaceutical Factory	Power Plant
Mining Industry	Traffic
Plating	Building
Pulp & Paper	Gasworks
Chemical Fertilizer	Machining
Food & Beverage

☉Applications:

Platform	Washing Rack	Machine Safety Protection
Floor	Bridge Sideway	Rail Cross-Cover Walkway
Stairs	Decoration Grating	Machine Maintenance Platform
Incline	Moveable Doors	Cargo Truck Proof's Walkway
Filters	Construction Frame	Airport Lighting Protection
Duct	Trench Covers	Cross-Cover Walkway
Railing	Ship Decking	Offshore Platform
Gangway	Vent Grating	Corrosion Resistance Cargo Ship

☉Available Resin Types For GRID:

Type	Resin Base	Description	Corrosion Resistance	Flame Spread Rating
V	Vinyl Ester	Superior corrosion resistance and fire retardant	Excellent	Class l(25)or less
I	Isophthalic Polyester	Chemical proof corrosion resistance and fire retardant	Very Good	Class l(25)or less
O	Orthophthalic Polyester	Good corrosion resistance and fire retardant	Good	Class l(25)or less
Food grade resins (Isophthalic Polyester) for food processing industry, and Flame retardant resins with Spread Rating of Class 1 (10) or less are available upon request. In addition, static resistant resin and phonelic resin are also available upon the special request.

Molded gratings

Sizes﹠Weight of Standard Molded FRP Gratings

Height (mm)	Mesh Size （mm×mm）	Bar Thickness (㎜)	Panel Size (mm×mm)	Open Area (%)	Unit Weight (kg/m2)	Panel Weight (kg)
1″(25)	1.5″×1.5″ (38.1×38.1)	0.25″ (6.4)	144″×48″ (3660×1220)	70	12	52
1″(25)	1″×4″ (25.4×101.6)	0.25″ (6.4)	144″×48″ (3660×1220)	64	15	67
1.5″(38)	1.5″×1.5″ (38.1×38.1)	0.25″ (6.4)	144″×48″ (3660×1220)	70	18	80
1.5″(38)	1.5″×6″ (38.1×152.4)	0.25″ (6.4)	144″×48″ (3660×1220)	73	19.5	87
2″(50)	2″×2″ (50.8×50.8)	0.25″ (6.4)	144″×48″ (3660×1220)	77	22	98
